model：lf-i/lf-iii
brand：jingxin
specifications ：lf-i/lf-iii
introduction：molecular hybridization furnace is an ideal equipment for modern laboratories to adopt hybridization technology.
product description:
molecular hybridization furnace is an ideal equipment for modern laboratories to adopt hybridization technology. it can replace plastic hybridization bags and water bath shakers, and avoid pollution hazards caused by damage. this machine adopts microchip control and hot air convection technology to provide urgent temperature control and a constant temperature environment. the air circulation device in the furnace is unique in design, and the heating speed is fast and even. this makes it an ideal hybridization system for northern and southern hybridization experiments. it also has a shaking base at the bottom, and it is also suitable for other incubation experiments with strict requirements such as placing hybridization bags.
features:
1. the microcomputer controller provides precise temperature control.
2. fast heating rate
3. tubular rotation, easy loading and unloading of hybridization tube
4. the interior is made of anti-corrosion, mirror stainless steel material
5. double-layer glass door design, effectively preventing radiation
product parameter comparison:
main parameters | parameter range | |
model | lf-i | lf-iii |
constant temperature range | room temperature＋5℃—100℃ | room temperature＋5℃—100℃ |
temperature control accuracy | ±0.5℃ | ±0.5℃ |
temperature uniformity error | ±0.03℃ | ±0.03℃ |
temperature display resolution | 0.1℃ | 0.1℃ |
temperature equilibration time | ＜20min | ＜20min |
spinning speed | 6.5±0.5r/min | adjustable speed |
continuous working time | 24 hours | 24 hours |
number of hybrid tubes | 6 big tubes | 6 big tubes |
voltage | 220vac，50hz | 220vac，50hz |
shake the base at the bottom | no | yes |
frequency | no | 0-33hz |
amplitude | no | 0-1mm |
outside size | 450*90*370mm | 450*390*400mm |
internal dimensions | 340*220*210mm | 340*220*220mm |
random hybrid tube | 35*240mm | 35*240mm |
basic configuration:
host: 1 set
ф35×240mm thermoelectric hybrid tube: 3
